Commercial Windows & Glass Systems for High Energy Performance & Savings

SeriousWindows Home

Commercial Home

Products

Heavy Commercial

Heavy Commercial Fiberglass SeriousWindows

7000 Series

Serious Energy, well known for its high performing, energy efficient residential window systems now brings to the commercial market the Heavy Commercial SeriousWindows Series, powered by SeriousGlass. Using sophisticated window technology, incorporating advanced glazing systems and super insulating fiberglass frames and sash, this next generation in energy efficient commercial window systems offers superior structural ratings, a variety of energy efficient, high thermal performance IGU packages, and full frame insulation values ranging from R-values R-3.0 to R-7.0.

Heavy Commercial SeriousWindows enable energy-efficient window strategies including passive heating and cooling coupled with maximum daylighting to reduce energy load and improve the environment for building occupants. In addition, there are many inherent advantages of fiberglass over aluminum framing systems including enhanced lifetime durability, higher thermal performance, and a lower embodied energy footprint.

7000 Series Datasheet

Performance
Glazing & Framing
Options
Warranty
Architectural Documents

AAMA Structural Performance Ratings
AAMA Paint Specifications
Thermal
Acoustic

Tested to AAMA/WDMA/ CSA 101/I.S.2./A440-08, the Heavy Commercial series achieves Heavy Commercial (CW) ratings across the line, as well as monumental or oversized ratings along with large mulled configuration in the heavy commercial category.

AAMA Gold Labeled
AAMA ratings (gateway sizes) CW100
Industry-leading air infiltration of <0.01 and water penetration of 15 psf
Durable, tough coatings warranted to meet AAMA 623-07 standards

AAMA Test Report Summaries: Heavy Commercial SeriousWindows

Window Style	AAMA/WDMA/CSA 101/I.S.2/A440-08	AAMA/WDMA/CSA 101/I.S.2/A440-05	ANSI/AAMA/NWWDA 101/I.S.2-97	Forced Entry Resistance	Operating Force - N (lbf)	Air Infiltration @75 Pa or 1.57 psf L/s/m2 (cfm/ft2 )	Water Penetration Resistance Test Pressure Pa (psf)	Uniform Load Structural Test Pressure Pa (psf)
Casement Window (24" x 60")	CW-PG100 (24" x 60")	C-C100 (24" x 60")	C-C100 (24" x 60")	Grade 10	9 (2)	<0.05 (<0.01)	720 (15.04)	±9331 (±195.00)
Casement Window (32" x 60")	CW-PG100 (32" x 60")	C-C100 (32" x 60")	C-C100 (32" x 60")	Grade 10	9 (2)	<0.05 (<0.01)	720 (15.04)	±7536 (±157.50)
Casement Window (36" x72")	CW-PG75 (36" x72")	C-C75 (36" x72")	C-C75 (36" x72")	Grade 10	9 (2)	<0.05 (<0.01)	720 (15.04)	±5400 (±112.78)
Awning Window (48" x 32")	CW-PG100 (48" x 32")	AP-C90 (48" x 32")	AP-C90 (48" x 32")	Grade 10	9 (2)	0.15 (.03)	720 (15.04)	±8254 (±172.50)
Awning Window (60" x 36")	CW-PG75 (60" x 36")	AP-C75 (60" x 36")	AP-C75 (60" x 36")	Grade 10	9 (2)	0.15 (.03)	720 (15.04)	±5400 (±112.78)
Picture Window (60" x 60")	CW-PG100 (60" x 60")	FW-HC100 (60" x 60")	FW-HC90 (60" x 60")	Grade 10	-	< 0.05 (< 0.01)	720 (15.03)	±7200 (±150.38)
Picture Window (96" x 72")	CW-PG60 (96" x 72")	FW-HC60 (96" x 72")	FW-HC60 (96" x 72")	Grade 10	-	< 0.05 (< 0.01)	720 (15.03)	±4320 (±90.23)

When you buy super-insulating fiberglass SeriousWindows, you can rest assured in knowing that you are getting high performance windows that meet the standards of AAMA (the American Architectural Manufacturers Association). AAMA, a third-party organization that is a leading industry source of performance standards and certification requires, test proceedures and performance requirments for organic coatings applied to AAMA certified SeriousWindows Fiberglass windows and doors.

AAMA Paint Specifications: 7000 Heavy Commercial Series

Specification Detail	AAMA 623	AAMA 624	AAMA 625
Weathering	South Florida	South Florida/Arizona	South Florida/Arizona
Color Retention	1 yr fade = 5 Delta E	5 yr fade = 5 Delta E	10 yr fade = 5 Delta E
Chalk Resitance	Color = No more than No. 8 White = No more than No.6	Color = No more than No. 8 White = No more than No.6	Color = No more than No. 8 White = No more than No.6
Gloss Retention	No Specification	5 yr 30% ret	10 yrs 50% ret
Erosion Resitance	No Specification	5 yrs 10%	10 yrs 10%
Chemical Reistance
Muriatic Acid	15 minutes/no attack	15 minutes/no attack	15 minutes/no attack
Mortar	24 hours/no attack	24 hours/no attack	24 hours/no attack
Nitrc Acid	No Specification	max 5D E units Change	max 5D E units Change
Detergent	72 hours/no attack	72 hours/no attack	72 hours/no attack
Window Cleaner	No Specification	24 hours/no attacks	24 hours/no attacks
Dry Film Thickness	0.8 mils minimum	1.2 mils minimum	1.2 mils minimum
Pretreatment System	No Specification	No Specification	No Specification
Accelerated Testing
Salt Spray	No Specification	No Specification	No Specification
Humidity	1,500 hrs	3,000 hrs	4,000 hrs

AAMA Specification Titles

AAMA 623-07 Organic Coatings on Fiber Reinforced Thermoset Profiles

AAMA 624-07 High Performance Organic Coatings on Fibere Reinforced Thermoset Profiles

AAMA 625-07 Superior Performance Organic Coatings on Fiber Reinforced Thermoset Profiles

Casement
U-Factor	R-Value	SHGC
0.36	2.8	0.29
0.33	3.0	0.29
0.29	3.4	0.41
0.27	3.7	0.28
0.26	3.8	0.36
0.25	4.0	0.3
0.24	4.2	0.24
0.23	4.3	0.21
0.19	5.3	0.17
0.19	5.3	0.21
Awning
U-Factor	R-Value	SHGC
0.36	2.8	0.29
0.33	3.0	0.29
0.29	3.4	0.41
0.27	3.7	0.28
0.26	3.8	0.36
0.25	4.0	0.3
0.24	4.2	0.24
0.23	4.3	0.21
0.19	5.3	0.17
0.19	5.3	0.21
U-Factor	R-Value	SHGC
0.38	2.6	0.22
0.35	2.9	0.33
0.30	3.3	0.48
0.26	3.8	0.30
0.26	3.8	0.42
0.25	4.0	0.42
0.24	4.2	0.28
0.23	4.3	0.24
0.20	5.0	0.19
0.19	5.3	0.25

The following are Outdoor Indoor Transmission Class Determination (OITC) test reports for this series. Test Method ASTM E90-09 was used to obtain the sound transmission loss data.

7000 Series Picture Window Outdoor Indoor Transmission Class Determination Test Report

7000 Series Casement Window Outdoor Indoor Transmission Class Determination Test Report

7000 Series Picture Window Sound Transmission Loss Test TL11-027

7000 Series Casement Window Sound Transmission Loss Test TL11-028

Glazing
Fiberglass Framing System

A Tuned, Customized Approach for Serious Energy Efficiency

Advanced glazing options enable architects to directionally “tune” a building by using different wavelength-selective coatings and glazing options according to a building’s unique location, orientation, and elevation. Architects can manage the sun to their advantage for greater building performance, energy-savings, and indoor comfort.

Each SeriousGlass platform includes a unique variety of packages including low and high solar heat gain, argon and krypton gas and gas mixtures, film and glass coatings.

Suspended film technology with warm edge spacer for improved thermal performance
1 1/8” overall insulated glass thickness
Variety of tinted, obscure, and laminated

Frame Color
Hardware
Styles and Sizes

Style	White	Black	Bronze	Silver Aluminum
Picture	Standard	Standard	Standard	Standard
Casement	Standard	Standard	Standard	Standard
Awning	Standard	Standard	Standard	Standard

Style	White	Beige	Coppertone	Black	Brushed Nickel	Oil Rubbed Bronze
Casement	Standard	Standard	Standard	Standard	Optional	Optional
Awning	Standard	Standard	Standard	Standard	Optional	Optional

	Casement	Awning	Picture
Style
Size	32” x 72”	60” x 36”	96” x 72”

warrantythumb100x128 Serious Materials is one of the few manufactures to offer a Full Limited Lifetime Warranty for all of our SeriousWindows commercial products.

10-Year Commercial Limited Warranty

Architectural Details/Drawings
CSI Specs
